Digital Rotational Viscometer HA-2, HB-2

₹272,580.00

Galaxy HA-2 & HB-2 viscometers are advanced digital viscometers that gives a direct readout of viscosity of any Newtonian fluid. It is specifically designed for high viscosity fluids.
Common Applications are : Gels, Chocolate, Epoxies, Asphalt, Caulking compounds, Molasses.

Categories: ,

Description

SALIENT FEATURES:
• Auto Range function.
• More number of speed options.
• Direct Viscosity reading and temperature display.
• Large bright back-light LCD Display.
• Viscosity value is accurate to 0.1 mpa.s.
• With automatic scanning function, the instrument can automatically recommend a suitable combination of rotor and speed.
• Can automatically display the range of viscosity that can be measured by the selected combination.

STANDARD ACCESSORIES:
• 6 spindles
• Spindle Guard Leg
• Power Cord
• Stand Set
• Instruction Manual

Specifications

Model HA-2 HB-2
Make Galaxy Galaxy
Measuring Range mpa.s 200~8,00,00,000 mpa.s 800~32,00,00,000 mpa.s
Measurement Resolution  0.1 mpa.s (Full scale)  0.1 mpa.s (Full scale)
Speed 0.1 to 100 RPM 0.1 to 200 RPM
No. of Speed 58 speed settings 58 speed settings
No. Standard Spindle 6 (R2, R3, R4, R5, R6, R7) 6 (R2, R3, R4, R5, R6, R7)
Display LCD LCD
Auto Scan Function Can automatically scan and recommend the
preferred combination of rotor and speed		 Can automatically scan and recommend the
preferred combination of rotor and speed
Temp. Monitoring Optional – Feature Available Optional – Feature Available
Measurement Accuracy ±1% F.S ± 1% F.S
Repeatability ± 0.5% F.S ± 0.5% F.S
Output RS 232C Interface RS 232C Interface
Power Supply AC 220 V / 50 Hz AC 220 V / 50 Hz
Dimensions & Weight 300 × 300 × 450 mm & 9 kgs 300 × 300 × 450 mm & 9 kgs

Downloads

Catalog GV-100 GV-200 Digital Rotational ViscometerDownload PDF
