Ultrasonic Cleaners (Lab Grade) Series

₹41,300.00

₹41,300.00

Salient Features:

Ultrasonic Cleaners Lab grade series is ideal for applications where operation time is shorter than 30 minutes. These ultrasonic cleaners can be used for a maximum of 30 minutes at a stretch, after 30 minutes of operation, 15 minutes of rest time is required before it can be used again.

Digital Ultrasonic cleaning is based on the cavitation effect caused by high frequency wave vibration in the fluid caused by the ultrasonic transducers. Microscopic bubbles are formed and the implode violently causing cavitation which creates an intense scrubbing action on the surface of the item being cleaned.

Ultrasonic Cleaning is extremely effective at removing dirt and grime which would normally require tedious manual cleaning by hand. It has been used to clean a wife variety of instruments and mechanical parts such as carburetors, toner heads, metal parts, gears, watches, surgical instruments, PCBS, etc returning them to almost like new condition without damaging parts.

STANDARD ACCESSORIES:

  • Main Instrument
  • Basket
  • Instruction Manual
  • Lid
  • Power Cord

Model

UC-1002

UC-1003

UC-1004

UC-1006

UC-1010

UC-1015

UC-1022

UC-1030

Theoritical Capacity

2.0L

3.2L

4.5L

6.5L

10.0L

15.0L

22.0L

30.0L

Actual water filling

1.6L

2.5L

3.5L

5L

8L

12L

18L

27L

Tank Size (mm)

150*135*100

240*135*100

300*150*100

300*150*150

300*240*150

330*300*150

500*300*150

500*300*200

Overall Size (mm)

180*165*205

270*185*230

330*180*240

375*200*275

330*270*310

360*330*310

530*330*310

530*325*325

Ultrasonic Power

60W

120W

180W

180W

240W

360W

480W

600W

Heating Power

100W

100W

200W

200W

200W

300W

500W

500W

Tank Drainage Valve

No

No

No

Yes

Yes

Yes

Yes

Yes

Time Setting

1-30 mins

1-30 mins

1-30 mins

1-30 mins

1-30 mins

1-30 mins

1-30 mins

1-30 mins

Heating Temp.

0-60°C

0-60°C

0-60°C

0-60°C

0-60°C

0-60°C

0-60°C

0-60°C

Display

LED

LED

LED

LED

LED

LED

LED

LED

Frequency

40kHz

40kHz

40kHz

40kHz

40kHz

40kHz

40kHz

40kHz

Lid Material

SS 204

SS 204

SS 204

SS 204

SS 204

SS 204

SS 204

SS 204

Inner Tank Material

SS 304

SS 304

SS 304

SS 304

SS 304

SS 304

SS 304

SS 304

Power Supply

AC 220V

AC 220V

AC 220V

AC 220V

AC 220V

AC 220V

AC 220V

AC 220V

Weight

2.4kg

3.6kg

4.9kg

5.4kg

7.5kg

10kg

11kg

18kg

Get A Callback
